Product features:
1. Adopting a single tube dual core structure, it can increase the pull rod, with high installation density and fast installation and removal
2. Compliant with Telcordia GR-326-CORE standard
3. The outer diameter of the optical cable can be selected from 2.0/3.0, and single and multi-mode options are available
Product Specifications：
|
参数 Parameters |
测试条件 Testing Parameters |
数值Measurements |
|
|
|
|
多模(Multimode)MM |
单横(Single-mode)SM |
|
插入损耗 Insertion Loss |
850/1300nm或者(or)1310/1550nm |
0.3dB |
0.3dB |
|
回波损耗 Return Loss |
850/1300nm或者(or)1310/1550nm |
≥35dB |
≥50dB(APC≥60) |
|
互换性 Interchangeability |
随机对接Randomized Connection |
<0.2 |
<0.2 |
|
抗拉强度 Tensile Strength |
70N |
<0.1 |
<0.1 |
|
工作温度 Operating Temperature |
-40°℃~80°℃ |
<0.2 |
<0.2 |
|
湿度 Humidity |
25℃~65℃,93%R.H,100h |
<0.2 |
<0.2 |
|
循环温度 Cycle Temperature |
40℃~85℃ |
<0.2 |
<0.2 |
Product application:
1 . Data center room
2. Fiber optic distribution frame
3. Local Area Network
4 . Fiber Channel
5. Communication network
6. Monitor the network
