Product features:
1. MPO connectors comply with standards such as IEC-61754-7 and GR-1435
2. Quick insertion and removal, convenient for construction operations
3. High wiring density, providing 12 to 144 core fiber optic connections, saving wiring space
4 . High compatibility, suitable for various application scenarios
5. Low loss
Product Specifications：
|
测试项目 Test Parameters |
多模Multimode (PC) |
单模Single-mode (APC) |
||
|
插入损耗 Insertion Loss(IL) |
标损 Standard Loss |
低损 Reduced Loss |
标损 Standard Loss |
低损 Reduced Loss |
|
|
≤0.5dB |
≤0.3dB |
≤0.7dB |
≥0.35dB |
|
回波损耗 Return Loss Return Loss(RL) |
≥25dB |
≥60dB |
||
|
工作温度 Operating Temperature(℃) |
-40~+85 |
|||
|
测试波长 Testing Wavelength(NM) |
850/1300 |
1310/1550 |
||
Product Application:
1. SAN (Storage Area Network) data center LAN
2. Parallel data exchange application between PCs
3.10G/40G/100G/400G network transmission
4 . Fiber optic cabling system
