Product features:
1. Modular design plug and play
2. High density, one module box can accommodate 12 LC duplex adapters or 12 SC adapters
3. The box body adopts integrated injection molding, which is lightweight and small in size
4 . Low consumption, high stability
Product Specifications：
|
型号Type |
最大插入损耗 Maximum insertion loss(dB) MPO LC/SC/FC/ST |
最大回波损耗 Maximum return loss(dB) MPO LC/SC/FC/ST |
||
|
OS2SM9/125 |
0.6 |
0.3 |
≥60(APC)≥50(PC) |
≥50 |
|
OM350/125 |
0.5 |
0.3 |
≥25 |
≥30 |
|
OM450/125 |
0.5 |
0.3 |
≥25 |
≥30 |
|
OM162.5/125 |
0.5 |
0.3 |
≥25 |
≥30 |
|
OM250/125 |
0.5 |
0.3 |
≥25 |
≥30 |
Product Application:
1.Data communication application
2.Data center infrastructure
3.Storage Area Network, Fiber Channel
4.Standard interface for 4.40G and 100G Ethernet transmission
